Product Details:
|
| Laser Power: | 1kw-20kw | Material: | Metal (cs, Ss, Aluminum, Brass, Copper) |
|---|---|---|---|
| Cutting Size: | 3000*1500mm | Warranty: | 3 Years |
| System: | CypCut / Au3tech (customized) | Servo Motor: | Japan Fuji / Yaskawa |
| Laser Source: | Raycus / Max / IPG | Max Cutting Speed: | 120m/min |
| Guide Rails: | Taiwan Hiwin | Transmission: | Taiwan YYC |
| Cutting Thickness: | 1-80mm | ||
| Highlight: | Stainless Steel Metal Laser Cutter,Carbon Steel Metal Laser Cutter,1KW Fiber Laser Metal Cutting Machine |
||
Product Features
●The bed adopts square tube/plate steel plate welding technology, With high temperature annealing and natural aging, the welding stress is eliminated,increase the structure strength and tensile strength.
●1300*900mm,1300*1300mm,3000*1500mm,4000*2000mm,6000*2000mm, other size can be customized.
●It support multiple graphic files include DXF, PLT, DWG, Al, G-code, IGS (tube cutting). It is compatible with other nesting software.
●It adopts the aviation Stretched aluminum gantry, extruded with 4300 tons of pressure, and processed by T6 heat treatment process, with high strength and strong resistance to deformation. Light weight, speed up movement.
|
Cutting size |
1390/1313/1325 |
3015/4015/4020 |
6015/6020/6025 |
|
Laser power |
1000w-20000w |
||
|
Laser source |
Max / Racus / Reci / Han / JPT / Au3tech |
||
|
Moving speed |
80m/min-180m/min |
||
|
Acceleration |
0.8G / 1.0G / 1.2G / 1.5G / 2.0G / 4.0G |
||
|
System |
CypCut / Au3tech |
||
|
Cutting head |
Raytools / Ospri / Boci / Precitec / Au3tech / WXS |
||
|
Servo motor |
Fuji / Yaskawa / Panasonic / INOVANCE |
||
|
Water chiller |
Hanli / S&A / DVT |
||
|
Voltage |
380V 50HZ / 60HZ (customized) |
||
|
Strong and Stable Structure The bed is welded with big thickness square tube/plate. which can guarantee a good stability and ensure good accuracy.
With high temperature annealing and natural aging, the welding stress is eliminated, which can prevent the deformation of the bed , reduce vibration and guarantee a good cutting accuracy. |
|
Aviation Grade Tensile Cast Aluminum Beam Machine adopts aviation tensile cast aluminum beam, which is manufactured according to the aerospace standards and extruded with 4300 tons pressure. The beam is processed by T6 heat treatment which can make the beam obtain the highest strength and strong deformation resistance |
|
|
CNC Bed Finishing Milling Center Each of our beds are finely ground with internal reinforcement added for rigidity and strength for longevity and machining accuracy |
|
Structure With High-temperature Aging Treatment In order to ensure the high precision, every equipment will be finished with fine milling and high-temperature aging treatment, the structure will not deform after long-term use. |
|
|
Cutting head / Raytools autofocus ● Long service life Full circulation water cooling around the focusing components, no heat and fog will be provided during high-power cutting, Small volume cutting, long time cutting, greatly increasing the service life of the cutting head. ● Excellent design Optimized optical configuration and smooth and efficient airflow design greatly improve cutting quality and efficiency. ● Several protective lenses A protective lens is added to the collimator to effectively protect the collimating lens. ● Mirror frame in the drawer Replacing protective lenses is quick and easy |
|
Laser Source / China Max Most importantly about laser cutting machines, Max is a leading designer and manufacturer of high performance fiber lasers and amplifiers for a variety of applications in many markets. Stable and economical. The new generation of Maxlaser lasers combines high power, compact size, easy handling, high beam quality and high light conversion efficiency. Can meet the requirements of precision machining. The welding of 3C products and the cutting ability of high-reflective materials have been greatly improved. Suitable for remoting. The laser cutting frequency is high and the cutting surface is smooth. Can be quickly and easily integrated into machine tools and automated production lines of large process manufacturers. |
|
|
Reducer / Japan Desbore The Desbore range of high precision gearboxes uses different types of gear technology. No matter what type of equipment we use, we can find the perfect fit in this high-precision product. |
|
Servo Motor / Japan Fuji ● Excellent stability: Stable operation without vibration is achieved even if the machine changes over time or the equipment differs. ● Embedded ptp positioning: The built-in positioning function can realize position control without purchasing a positioning device. ● Simple operation: Through Modbus-RTU communication, HMI, general-purpose PLC, PC controller, etc. can be directly connected to the servo amplifier for ptp positioning operation, parameter editing and various monitoring. ● Easily replaceable ABS battery: Use a simple absolute encoder abs battery replacement, and a spare abs battery can be installed on the front of the servo. ● Wide range of applications: The self-tuning function has been added to optimize settings for equipment with low rigidity. Even long belt designs, gears with large backlash, or rack-and-pinion designs can be easily adjusted with smart function |
|
|
Intelligent Software With Alarm Function
Adopts high definition toughened glass, intelligent touch, fast response and smoother operation. Ultra-low power consumption and high resolution. The new intelligent alarm system is pushed to the interface through the control center to find abnormalities in advance, quickly eliminate and feed back, reduce hidden dangers, and there is no danger in remote alarm operation |
Materials:
The fiber Laser Cutting machine can cut many metal materials, such as stainless steel, carbon steel, alloy steel, silicon steel, spring steel, aluminum,
aluminum alloy, galvanized plate, aluminized zinc plate, pickling plate, copper, silver, gold, titanium, and other metal plates and pipes.
