1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine

All Products

Fiber Laser Cutting Machine

(54)

Metal Pipe Laser Cutting Machine

(8)

Sheet And Tube Laser Cutting Machine

(29)

Metal Laser Cutter

(5)

Fiber Laser Tube Cutter

(9)

Small Fiber Laser Cutting Machine

(19)

High Precision Fiber Laser Cutting Machine

(10)

Sheet Metal Laser Cutter

(19)

Laser Welding Machine

(10)

Fiber Laser Welder

(10)

Laser Cleaning Machine

(10)

Laser Rust Removal Machine

(10)
Certification
China Jinan Zhongli Laser Equipment Co., Ltd. certification
Customer Reviews
This is Derek from UK. We bought one 3000w fiber laser cutter from ZLTECH on year 2010. Their engineer David provided us technical support and machine works very well. I will be in touch with ZLTECH next year for one bigger power laser.

—— Derek from UK

This is Seif from Israel, one of my friend recommended ZLTECH to me and I bought one enclosed fiber laser cutting machine from them.Machine runs perfectly and it helped us a lot, its cutting accuracy is much better than our old plasma cutter.

—— Seif from Israel

I'm Online Chat Now

1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine

1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine

Large Image :  1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine

Product Details:
Place of Origin: CHINA
Brand Name: ZLTECH
Certification: CE,FDA
Model Number: ZL-1325A
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD12000-25000 per Piece
Packaging Details: Plastic protective film, export plywood box
Delivery Time: 10-30days
Payment Terms: T/T, D/P, L/C, Western Union, MoneyGram, D/A
Supply Ability: 60pcs/month
Contact Now

1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine

Description
Application: Metal Plate Laser Cutting Cutting Area: 1300*2500mm
Graphic Format Supported: AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP Cooling Mode: WATER COOLING
Laser Source Brand: MAX; IPG, Raycus,JPT Servo Motor Brand: Japan Fuji, Japan Yaskawa,Panasomic, Delta
Control System Brand: Cypcut Laser Power: 1000W/1500W/2000W/3000W/4000W/6000W/8000W/10000W/12000W/20000W
Voltage: 3 Phase,380v,50Hz Or Customized Cutting Materials: Stainless Steel/Carbon Steel/Copper/Brass/Iron/MS
Laser Head Brand: Raytools,Au3tech, Precitec,Worthing, Empower,WSX Warranty: 3 Years
Highlight:

Stainless Steel Fiber Cutting Laser Machine

,

Economic Fiber Cutting Laser Machine

,

1300x2500mm fiber laser 1000w

1300*2500mm Economic Stainless Steel Fiber Laser Cutting Machine Metal Cutter For Stainless Steel Cutting

Product Paramenters
1
Product Name
Metal Fiber Laser Cutting Machine
2
Product Model
ZL-1325A
3
Cutting Size
1300mm×2500mm
4
Power
1000W 2000W 3000W 4000W 6000W 8000W 10000W 12000W 20000W
5
Max Moving Speed
120m/min
6
Position Accuracy
0.01mm/m
7
Fiber Laser Source
Raycyus /Max/ IPG
8
Motor&Drivers Brand
Japanese Fuji/Yaskawa / Taiwan Delta
9
Cutting Head
Raytools / Precitec
10
Control System
CpyCut
11
Ruducer
Japanese Shimpo/ French Motovario/ Germany Neugart
12
Guide
Taiwan Hiwin
13
Rack
Taiwan YYC/APEX Germany HERION,etc
14
Water chiller
Hanli/Tongfei/S&A,etc.
15
Compatible Software
CorelDraw/AutoCAD/Photoshop/AI
16
Support Graphic Format
LXD/.DXF/.PLT/.AI/.Gerber/.DWG



Product Overview
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 0
Single Platform Fiber Laser Cutting Machine
It is a high-performance single working table fiber cutting machine. The bed adopts a 6mm welding process, and has annealing treatment process and high precision milling to increase the strength. Internal reinforcing ribs increase tensile resistance and toughness. The gantry is extruded with 4300 tons of pressure and processed by T6 heat treatment process. It has high strength and strong resistance to deformation. Light weight, speed up the movement, the machine adopts Japanese servo motor, German rack, automatic cutting head and other configurations, showing good performance quality.
Sample Display
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 1

Product Quality
Hollow Design Stable & Strong Welded Steel Bed
It is a high efficiency fiber cutting machine for metal cutting. The machine adopts big thickness bed, which is processed with high temperature annealing and natural aging, the welding stress is eliminated, which can prevent the deformation of the bed , reduce vibration and guarantee a good cutting accuracy. The gantry is extruded with 4300 tons of pressure and processed by T6 heat treatment process. It has high strength and strong resistance to deformation. Our fiber laser cutter adopts Japan servo motor, German rack, automatic cutting head and other good quality parts, which can guarantee a super cutting performance.
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 2
The Third Generation Of Aviation Cast Aluminum Alloy Beam
Machine adopts aviation cast aluminum alloy beam, which is manufactured according to the aerospace standards and extruded with 4300 tons pressure. The beam is processed by T6 heat treatment which can make the beam obtain the highest strength and strong deformation resistance.
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 3
Swiss Raytools Auto Focus Laser Cutting Head
Laser head with automatic focus funtion, which can adjust the focus automatically, no need to adjust it by hand. The software can change the focusing lenses auotmatically according to the different thickness of the materials. It can shorten the perforation time,improve the perforation quality and cutting speed. It’s simple, convenient and fast.
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 4
Dust-proof Electrical Cabinet With Air Conditioner
We put all electrical components and laser source into the independent control box, it is dust proof which can guarantee the life span of the components.
Also we add the air conditioner on the control cabinets, which can keep the constant temperature automatically. It can prevent the high temperature damage for the components in summer.
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 5
Intelligent Software With Alarm Function
Adopts high definition toughened glass, intelligent touch, fast response and smoother operation. Ultra low power consumption and high resolution.
The new intelligent alarm system is pushed to the interface through the control center to find abnormalities in advance, quickly eliminate and feed back, reduce hidden dangers, and there is no danger in remote alarm operation.
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 6
Servo Motor & Drivers
High speed,high precision,high reliability,high power.Gantry double drive mechanism has high damping coefficient, good rigidity,could
withstand high speed and high acceleration.
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 7
Taiwa original YYC rack and Hiwin guide rail
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 8
Company Profile
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 9
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 10
ZLTECH Laser is a professional manufacturer of fiber laser cutting machine. We have strict and systematic quality control for each process, from material, production to delivery. We use high-tech precision instruments to measure the accuracy and transmission speed of the machine. The main tests include track transmission accuracy level test, cutting head vertical test, bed parallel and vertical test, etc. In order to ensure high precision, each equipment has undergone fine milling and high temperature aging treatment, and the structure will not be deformed after long-term use. To provide customers with tailor-made services to meet different work needs, ZLTECH has established an independent R&D department with 12 professional engineers. ZLTECH will update and innovate regularly.

Successful factory

We are one of the largest laser machine factories in China. We have many professional designers and sellers. We have sold our machines to more than 80 countries and the number has been increasing.

1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 11

We pay attention to every detail

It is our research on every detail of the product and every process inspection that makes us stand out. We are creative and pay close attention to the details you care about most.

Competitive pricing

1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 12
Our prices are competitive and fair. No unexpected bills. Any unexpected or additional costs must be approved by you in advance.This is how we want to be treated and how our customers are treated.

High-quality bed made by ourselves

All the beds are made by ourselves and are mass production.The production time and quality of the machine were completely controlled by our own company.
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 13
Reliable after-sales service
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 14
Packing & Shipping
1300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 151300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 161300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 171300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 181300x2500mm Economic Stainless Steel Fiber Cutting Laser Machine 19
FAQ
1.Are you a factory or a foreign trade company?
We have factory production machines and the price is very competitive.
We have after-sales technology to provide 24-hour service

2. Why we can choose you?
1): Reliable---we are the real company, we dedicate in win-win.
2): Professional---we offer design and configurations want.
3): Factory---we have factory, so have reasonable price. No unexpected bills.
Any unexpected or additional expenses must be approved by you in advance.

3.How about the shipping cost?
Sea transportation, we choose 20-foot container or 40-foot container according to the size you buy.
We have a shipping company that has cooperated for many years, which can help you save costs.

4.How about the price?Can you make it cheaper?
The price depends on your needs (function, size, quantity) We will quote you the best discount after receiving your inquiry

5.How about the payment?
T/T,20% deposit, and balance is after the order is finished. Also we accept the PAYPAL, west union,etc.
